7 - MAINTENANCE
x For the versions with a grill with flaps, insert the two lugs (fig. 7.5 ref. A) into the special slots (fig. 7.5 ref. B), turn it and hook it up
with a slight tap on the upper part.
x For the versions with a mobile panel, rest it in its position, parallel to the front panel and press until it is blocked
7.7 Ending clearing operations
fig 7.4
fig 7.5
M09160D17-02 87
