8 - TECHNICAL INFORMATION
GENERAL TECHNICAL SPECIFICATIONS
Voltage: 230/1/50
ELECTRICAL DATA
Size
003.0 005.0 011.0 015.0 017.0
COOLING
Cooling capacity 1 kW 0,89 1,91 2,83 3,69 4,19
Sensible capacity 1 kW 0,65 1,29 1,94 2,5 2,78
Total power input 1 kW 0,012 0,02 0,022 0,03 0,033
HEATING
Heating capacity 2 kW 0,93 1,97 2,71 3,45 4,11
INTERNAL EXCHANGER
Water content
l 0,47 0,8 1,13 1,46 1,8
Water flow-rate 1 l/s 0,04 0,084 0,126 0,16 0,182
Pressure drop 1 kPa 7,2 8,4 22,5 18,6 24,9
AIR HANDLING SECTION FANS (OUTLET)
Type of supply fan 3 TGZ TGZ TGZ TGZ TGZ
Supply air flow rate 4 l/s 45 89 128 160 180
CONNECTIONS
Water fittings
Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4 Eurokonus 3/4
Condensate discharge
14 14 14 14 14
POWER SUPPLY
Standard power supply
V 230/1/50 230/1/50 230/1/50 230/1/50 230/1/50
(1) Ambient temperature 27°C/19.5 WB; water inlet 7°C and outlet 12°C
(2) Ambient temperature 20°C DB water inlet 45°C and outlet 40°C
(3) TGZ=tangential
(4) Air flow at max speed measured with clean filters
(5) power supply 230/1/50 Hz +/-10%
Size
003.0 005.0 011.0 015.0 017.0
F.L.A. - FULL LOAD CURRENT AT MAX ADMISSIBLE CONDITIONS
F.L.A. - Total
A 0,11 0,16 0,18 0,26 0,28
F.L.I. FULL LOAD POWER INPUT AT MAX ADMISSIBLE CONDITION
F.L.I. - Total
kW 0,012 0,02 0,022 0,03 0,033
power supply 230/1/50 Hz. Voltage variation: max. -/+10%
OPERATING LIMITS (COOLING)
Size
003.0 005.0 011.0 015.0 017.0
INTERNAL EXCHANGER
OPERATING LIMITS (HEATING)
INTERNAL EXCHANGER
Max inlet water temperature
°C 80 80 80 80 80
Min. water inlet temperature
°C 30 30 30 30 30
Min. air temperature inlet (D.B.)
°C 5 5 5 5 5
Maximum water side pressure
bar 10 10 10 10 10
Size
003.0 005.0 011.0 015.0 017.0
OPERATING LIMITS
Max inlet water temperature
°C 20 20 20 20 20
Min. water inlet temperature
°C 4 4 4 4 4
Max. air temperature inlet (D.B.)
°C 32 32 32 32 32
Min. air temperature inlet (D.B.)
°C 5 5 5 5 5
Maximum water side pressure
bar 10 10 10 10 10
M09160D17-02 91
