54
EVH-X SPACE 2.1 - 12.1
M0SM10N17-03
11 GENERAL TECHNICAL DATA
Contains fluorinated greenhouse gases (GWP 2087,5)
The Product is compliant with the Erp (Energy Related Products) European
Directive. It includes the Commission delegated Regulation (EU) No 2016/2281,
also known as Ecodesign Lot21.
A 27/19 W 30 = Unit inlet air temperature 27°C D.B. / 19°C W.B. Unit inlet
water temperature
A 20 W 20 = Unit inlet air temperature 20°C Unit inlet water temperature 20°C
DB = Dry bulb WB = Wet bulb
1 Ambient air 27°C D.B./19°C W.B. Exchanger water temperature 30°C / 35°C.
Values read in compliance with EN14511:2018 and including the required
system fan motor and water pump capacity for overcoming pressure drops
inside the unit.
2 SEER e SCOP in conformità EN 14825-2016.
3 Prestazioni lorda. Ambient air 27°C D.B./19°C W.B. Exchanger water
temperature 30°C / 35°C. The value does not take into account the power
of the fan’s motor and the part related to the pumps and required to
overcome the pressure drops for the circulation of the solution inside the
exchangers.
4 Ambient air 20°C D.B. Exchanger inlet water temperature 20°C. The water
temperature at the exchanger output is read in relation to the flow of
water being chilled. Values read in compliance with EN14511:2018 and
including the required system fan motor and water pump capacity for
overcoming pressure drops inside the unit.
5 Ambient air 20°C D.B. Exchanger inlet water temperature 20°C. The value
does not take into account the power of the fan’s motor and the part
related to the pumps and required to overcome the pressure drops for the
circulation of the solution inside the exchangers
6 ROT = Rotary compressor. SCROLL = Scroll compressor
7 CFG = Centrifugal fan
8 Standard airflow
9 Available static pressure with standard air flow and clean air filter
10 Water flow calculated in relation to the performances in cooling.
11 Total pressure drop of the standard unit (without optional hydraulic pipe
works). To obtain the total drops with any additional hydraulic components
see accessory section.
12 Water inlet/outlet diameter
13 Condensation drain pipe, external diameter
Size 2.1 3.1 5.1 7.1 10.1 12.1
Cooling A 27/19 W 30
Cooling capacity (EN14511:2018) 1 [kW] 4,56 8,08 10,6 16,9 25,0 28,9
Total power input (EN14511:2018) 1 [kW] 1,30 2,07 3,04 4,15 5,85 7,43
EER (EN14511:208) 1 3,52 3,90 3,53 4,07 4,27 3,89
SEER 2 3,28 3,93 3,57 4,23 4,47 3,97
Cooling capacity 3 [kW] 4,81 8,46 11,2 17,9 25,9 30,8
Sensible capacity 3 [kW] 3,74 6,44 8,84 13,9 20,0 22,4
Compressor power input 3 [kW] 0,96 1,61 2,27 3,07 4,74 5,36
Total power input 3 [kW] 1,34 2,09 3,13 4,29 6,11 7,75
Heating A 20 W 20
Heating capacity (EN14511:2018) 4 [kW] 7,55 10,3 14,4 23,1 33,2 38,2
Total power input (EN14511:2018) 4 [kW] 1,75 2,39 3,35 5,23 7,21 8,47
COP (EN14511:2018) 4 4,30 4,31 4,30 4,41 4,60 4,52
SCOP 2 3,81 3,82 3,81 3,91 4,08 4,01
Heating capacity 5 [kW] 7,06 9,83 13,5 22,1 32,3 36,4
Compressor power input 5 [kW] 1,46 1,99 2,56 4,02 6,04 6,23
Total power input 5 [kW] 1,76 2,4 3,4 5,3 7,3 8,6
Compressor
Type of compressors 6 ROT ROT ROT SCROLL
SCROLL SCROLL
No. of compressors 1 1 1 1 1 1
Refrigerant charge kg 0,7 0,95 1,1 1,3 3,2 4,1
Air Handling Section Fans (Supply)
Type of fans 7 CFG CFG CFG CFG CFG CFG
No. of fans 1 1 1 1 1 1
Airflow 8 l/s 278 416 778 1056 1351 1657
Max external static pressure 9 Pa 250 270 290 310 220 410
External section
Water flow-rate 10 l/s 0,27 0,47 0,64 1,00 1,47 1,72
Pressure drop 11 kPa 13,0
15,8 17,6 19,4 18,6 20,4
Connections
Water fittings 12 1" 1" 1" 1" 1"1/2 1"1/2
Condensate drain 13 22 22 22 22 22 22
Power supply
Standard power supply 220-240/1/50 380-415/3/50 +N
Airflow
m
3
/h 1000 1500 2800 3800 4900 6000
