MODBUS registers

10. MODBUS registers

10.1 Controls

Address

Meaning Description

0 ON/OFF

bit15 Reserved

bit14 Reserved

bit13 Reserved

bit12 Reserved

bit11 Reserved

bit10 Reserved

bit9 Reserved

bit8 Reserved

bit7 Reserved

bit6 Reserved

bit5 Reserved

bit4 Reserved

bit3 0= o (T2S); 1= on (T2S) (WATER FLOW TEMP control - zone

bit2 0= DHW (T5S) o; 1= DHW (T5S) on

bit1 0= o (T1S); 1= on (T1S) (WATER FLOW TEMP control - zone 1)

bit0 0= o (TS) 1= on (TS) (ROOM TEMP thermostat control)

1 Operation mode 1: auto; 2: Cooling ; 3: heating ; other value: invalid

2 Set water temp. T1s

bit8-bit15

Water temp. T1s setting for ZONE 2

bit0-bit7 Water temp. T1s setting for ZONE 1

3 Set air temperature Ts

Room temperature setting, when a valid Ta is present, 17°C ~ 30°C

transmission value equal to actual value * 2; 35 is transmitted, e.g.17.5°C

4 T5s

Storage tank water temperature setting, 20°C ~ 60/75°C (EDGE A with

AHS can be set at 75°C, other unit at 60°C) Default =50°C
