CLIVET WSAN-XIN 21 - Scheduling Management

30
Hour tE31 tE59 tE87
Minutes tE32 tE60 tE88
Mode 0= on
1= standby
tE33 tE61 tE89
Cooling
temperature
tE34 tE62 tE90
Heating
temperature
tE35 tE63 tE91
DHW
temperature
tE36 tE64 tE92
Hour tE24 tE52 tE80
Minutes tE25 tE53 tE81
Mode 0= on
1= standby
tE26 tE54 tE82
Cooling
temperature
tE27 tE55 tE83
Heating
temperature
tE28 tE56 tE84
DHW
temperature
tE29 tE57 tE85
Hour tE17 tE45 tE73
Minutes tE18 tE50 tE74
Mode 0= on
1= standby
tE19 tE47 tE75
Cooling
temperature
tE20 tE48 tE76
Heating
temperature
tE21 tE49 tE77
DHW
temperature
tE22 tE50 tE78
7 - CONTROL
Main menu Parameter modification
Parameters
tE
tE00
It is possible to set 3 different schedulings.
To each schedulino is possible to associate 4 events.
To each day of the week is possible to associate a scheduling.
In the example the schedulings have been assigned:
scheduling 1 Monday, Tuesday, Wednesday
scheduling 2 Thursday, Friday
scheduling 3 Saturday, Sunday
Day
Scheduling
1
Scheduling
2
Scheduling
3
Monday
tE01 = 1 - -
Tuesday
tE02 = 1 - -
Wednesday
tE03 = 1 - -
Thursday
- tE04 = 2 -
Friday
- tE05 = 2 -
Saturday
- - tE06 = 3
Sunday
- - tE07 = 3
Description Event 1 Event 2 Event 3
Hour
tE10 = 07 tE17 = 12 tE24 = 16
Minutes
tE11 = 00 tE18 = 00 tE25 = 30
Mode 0= on
1= standby
tE12 = 0 tE19 = 0 tE26 = 0
*Cooling
temperature
tE13 = -
tE20 = - tE27 = -
*Heating
temperature
tE14 = 20
tE21 = 22 tE28 = 22
DHW
temperature
tE15 = 45
tE22 = 45 tE29 = 55
Scheduling 1
Event 4
tE31 = 22
tE32 = 00
tE33 = 0
tE34 = -
tE35 = 18
tE36 = 45
In the following example the scheduling 1 schedules:
at 07:00 changes the heating set-point
at 12:00 changes the heating set-point
at 16:30 changes the DHW set-point
at 22:00 changes the heating set-point and DHW
Sched. 1
(par.)
Sched.2
(par.)
Sched.3
(par.)
Hour
tE10 tE38 tE66
Minutes tE11 tE39 tE67
Mode 0= on
1= standby
tE12 tE40 tE68
Cooling
temperature
tE13 tE41 tE69
Heating
temperature
tE14 tE42 tE70
DHW
temperature
tE15 tE43 tE71
Event 2 Event 3 Event 4 Event 1
* If the unit is in Cooling is used the cooling temperature.
* If the unit is in Heating is used the heating temperature.
7.3 SCHEDULING MANAGEMENT
To enable the hour scheduling :
Par tE00 hour scheduling
0 = disabled , 1 = enabled
Par CL43 = -2 (see pag 15)
