1 - GENERAL
1.5 ACCESSORIES
CONFIGURATIONS
400TN Supply voltage 400/3/50+N
230M Supply voltage 230/1/50
HYDRAULIC CIRCUIT
GCEC High efficiency EC circulation group
- Hydronic group utility side: not required
KTFL1X Water connection hoses with 1"
ELECTRIC CIRCUIT
RCTX Remote control with keyboard room
CMACSX Domestic hot water module
CMSC2X Serial communication module with RS485 serial
converter kit
INSTALLATION
AMRX Rubber antivibration mounts
X : separately supplied accessories
1.4 UNIT INDENTIFICATION
Serial number label
The serial number label is positioned on the unit and allows to
indentify all the unit features.
It has not to be removed for any reason.
It reports the regulations indications such as:
• machine type, exmple:
Series WSAN-Xin
Size 21...41...
• serial number
12 characters Axxxxxxxxxxx
• year of manufacture
• wiring diagram number
• electrical data
• manufacturer logo and address .
Serial number
It identifies uniquely each machine.
It identifies specific spare parts for the machine.
Assistance request
Note data from the serial number label and write them in the
chart on side, so you will find them easily when needed.
In case of intervention you have to provide data.
Serie
Size
Serial number
Year of manufacture
Wiring diagram
