CLIVET WSAN-XIN 21 - Customer Electrical Wiring

14
5 - ELECTRICAL CONNECTIONS
5.7 CUSTOMER CONNECTIONS
1 Unit
2 Customer connections
3 Only for size 21-41
4 Only for size 51-71
A fuses (provided by the Customer)
B isolator switch (provided by the Customer)
FU1 fuses
QG electrical panel
KA3 relè
XT1 terminal block of the Customer connections
ALM alarm
AP7 ambient keyboard
SA2 remote SUMMER-WINTER
SA1 remote ON-OFF
M8 pump utility
1
2
230/1/50
14 61 81
M8
CN1-7
CN1-14 CN1-12
CN2-6
+12VDC
SIGN
GND
CN2-7
CN2-8
SA1 SA2
3 4
ALM
1
2
400/3/50+N
14 61 81
CN1-7
CN1-14 CN1-12
CN2-6
+12VDC
SIGN
GND
CN2-7
CN2-8
M8
SA1
SA2
ALM
