Cloud 24 Series User Manual

24 Series Installation and User Guide V1.0
29
Power consumption
Standby
1
24-120 5.74 W (15.48 VA)
24-240 5.88 W (24.92 VA)
Idle
2
24-120 17.12 W (28.49 VA)
24-240 18.74 W (36.11 VA)
1/8
th
Power
3
24-120 56.46 W (65.88 VA)
24-240 90.79 W (108.99 VA)
1/3
rd
Power
4
24-120 106.17 W (114.90 VA)
24-240 183.96 W (207.16 VA)
Heat Loss
Standby
1
24-120 20.67 kJ/hr (19.6 BTU/hr)
24-240 21.17 kJ/hr (20.07 BTU/hr)
Idle
2
24-120 61.63 kJ/hr (58.45 BTU/hr)
24-240 67.46 kJ/hr (63.98 BTU/hr)
1/8
th
Power
3
24-120 102.71 kJ/hr (97.40 BTU/hr)
24-240 124.17 kJ/hr (117.75 BTU/hr)
1/3
rd
Power
4
24-120 136.95 kJ/hr (129.88 BTU/hr)
24-240 179.81 kJ/hr (170.52 BTU/hr)
Dimensions (W x H x D)
Net
24-120
482.6 mm x 44 mm (1U) x 150 mm
19” x 1.75” (1U) x 5.9”
(less connectors & knobs)
24-240
482.6 mm x 44 mm (1U) x 230 mm
19” x 1.75” (1U) x 9.06”
(less connectors & knobs)
Shipping (Gross) 545 mm x 160 mm x 330 mm (21.5” x 6.3” x 13.0”)
Weights
Net
24-120 2.35 kg (5.26 lb)
24-240 3.05 kg (6.83 lb)
Shipping
24-120 3.4 kg (7.62 lb)
24-240 4.1 kg (9.2 lb)
Notes re Power Consumption and Heat Loss measurements:
All measurements at 230 VAC 50 Hz power input
1. Standby: amplier in standby state (STATUS LED steady red)
2. Idle: amplier not in standby state (STATUS LED steady green), but no audio output
3. 1/8
th
. Power: constant sound level at one-eighth maximum rated output (audio mainly clean, only occasional clipping)
4. 1/3
rd
. Power: constant sound level at one-third maximum rated output (audio beginning to become compressed, limited or heavily clipped)

Cloud 24 Series Specifications

General

Type	Power Amplifier
Channels	2
Signal-to-Noise Ratio	>100dB
Damping Factor	>200
Frequency Response	20Hz - 20kHz
Input Impedance	20k ohms
Cooling	Convection
