CX263 Installation and User Guide v1.1
21
Technical Specications
Line Inputs:
Frequency response 20 Hz to 22 kHz, +0/-0.5 dB
Distortion <0.05% typical, 20 Hz to 22 kHz
Sensitivity 100 mV (-17.8 dBu) to 1.5 V (+6 dBu)
Input gain control range 24 dB
Input impedance 48 kohms
Headroom >20 dB
Noise <-84 dB, 20 Hz to 22 kHz @ 0 dB gain
Equalisation LF: +/-10 dB @ 50 Hz; HF: +/-10 dB @ 10 kHz
Microphone Inputs:
Frequency response -3 dB @ 100 Hz (lter) to 20 kHz, +/-0.5 dB
Distortion <0.05%, 20 Hz to 22 kHz
Gain range 10 dB to 50 dB
Input impedance >2 kohms
Common mode rejection >70 dB @ 1 kHz
Headroom >20 dB
Noise -128 dB EIN, 20 Hz to 22 kHz @ 0dB gain
Equalisation LF: +/-10 dB @ 150 Hz; HF: +/-10 dB @ 5 kHz
Outputs:
Output level (nominal) 0 dBu
Output level (max.) +20 dBu
Minimum load impedance 1.2 kohms
General:
Power input 85 V to 253 V AC, 50/60 Hz
Current consumption 43.1 mA at 240 V
Fuse rating 1 A
Fuse type T1A, 20 x 5 mm
Dimensions (WxHxD)
482.6 mm x 44 mm (1U) x 152.5 mm
19” x 1.73” (1U) x 6”
Weight
2.13 kg
4.66 lbs
