CMC S19N User Manual

MAN.219 Rev.8 ENG - Use and maintenance manual S19N page 4 of 71
1 Specifications  
1.1 Technical sheet 
PERFORMANCE
Max. working height
18,90 m
62.00 ft
Max. work outreach (with 230 kg)
8,30 m
27.23 ft
Max. work outreach (with 120 kg)
9,50 m
31.17 ft
Max. load on the basket
230 kg
507 lb
Turret rotation
+/-178° (total 356°)
Basket rotation
NOT AVAILABLE
Max. slope to stabilize on obstacle
6° / 11%
Max. slope of ramp attack
(with jib lifted/engine side)
18°-13° / 32%-23%
Max. slope to travel
longitudinally/transversally
17°-10° / 31%-18%
Travel speed
0,7 - 1,4 km/h
0.43 - 0.87 mph
DIMENSIONS
Basket height
1,10 m
3.61 ft
Basket width
0,70 m
2.30 ft
Basket length
0,80/1,20/1,40 m
2.62/3.94/4.59 ft
Total length with basket
4,95 m
16.24 ft
Total length without basket
4,41 m
14.47 ft
Height in driving position
1,98 m
6.50 ft
Total width (without basket)
0,79 m
2.59 ft
Clearance from the ground
in transport configuration
0,22 m
0.72 ft
Max. height to stabilize
on obstacle
0,45 m
1.48 ft
Tracks (l x h)
1,45x0,18x0,30 m
4.76x0.59x0,98 ft
Width tracks adjustment
(*optional)
0,78/1,08 m
2.56/3.54 ft
Longitudinal stabilization
3,58 m
11.75 ft
Cross stabilization
2,84 m
9.32 ft
Outriggers plate Ø
0,18 m
0.59 ft
WEIGHT AND PRESSURES
Total weight (standard equipment)
2435 kg
5368 lb
(R) Max. pressure on the foot
6,30 Kg/cm²
(61,78 N/cm
2
)
89.61 lb/in
2
(S) Max. pressure on the track
0,87 Kg/cm²
(8,53 N/cm
2
)
12.37 lb/in
2
(T) Max. pressure in travel
313 Kg/m²
(3,07 KN/m
2
)
64.11 lb/ft
2
(U) Max. pressure in work
(4 feet opened)
205 Kg/m²
(2,01 KN/m
2
)
41.99 lb/ft
2
POWERS
Standard hydraulic feed
1) Honda iGX390 petrol, 8.7 kW (11.7 HP),
3600 rpm
*Optional feeds
2) Yanmar L100 diesel, 6.8 kW (9.1 HP), 3600
rpm
3) Kubota Z482-E4B diesel, 9.9 kW (13.3 HP),
3600 rpm
4) Electric engine 110/120/230 V
5) Motor G0901306, 9 kW, 48 V, with lithium
batteries 100 Ah
Fuel tank capacity
6,1/15 l
