17
USB MIDI Master Keyboard
nel for the second voice than the first voice. However, you can change the
MIDI channel after turning on the dual function.
3. When SPLIT function is turned on, DUAL function will be automatically
turned off. You cannot turn on DUAL function when SPLIT function is on.
3.7 After touch (A.TOUCH)
A.TOUCH is the switch for the channel after touch function.
3.7.1 By pushing A.TOUCH button, you can turn on or off the after
touch function of the keyboard, to allow or permit the after touch mes-
sage from the keyboard.
Note: This function only works when the keyboard is powered by the AC. Adapter.
3.8 Drawbar organ (DRAWBAR)
With the drawbar organ function, you can use fader CS0-CS8 as
drawbars to adjust organ voice.
3.8.1 When DRAWBAR function is on, fader CS0-CS8 work as below:
Fader func CS0 CS1 CS2 CS3 CS4 CS5 CS6 CS7 CS8
Channel Current Current Current Current Current Current Current Current Current
Organ bar 16' 5 1/3' 8' 4' 2 2/3' 2' 1 3/5' 1 1/3' 1'
Controller# 12 13 14 15 16 17 18 19 20
Default 64 64 64 64 64 64 64 64 64
Value range 127-0 127-0 127-0 127-0 127-0 127-0 127-0 127-0 127-0
Hint:
If you tone generator does not support drawbar organ mode, the draw-
bar function of the keyboard will not work.
4. Computer music system connection
4.1 Sequencer remote control
There are 6 sequencer control buttons. When the UF keyboard
is connected to a computer, you can use those buttons to send MIDI
sync commands, to control PLAY, REC, F.F., REW etc... in the music
software.
4.1.1 The 6 buttons are: Top Rewind Forward Record Stop Play.
Hints:
1.Those functions need software support, and you must make the right
setup in the software before you can use those buttons properly.
Computer music system connection
