CME UF5 User Manual

7
USB MIDI Master Keyboard
Connection
USB cable for bi-direction data transmission.
CABLE HOOK
Keep the power cord in the CALBE HOOK when necessary for
good power connection.
POWER INLET
Power supply goes from the A.C. adapter to the POWER INLET.
POWER SWITCH
POWER SWITCH is used to turn on or turn off the UF keyboard.
1.3 Connect UF to tone generators
Warning: Turn off all the devices before connection
Connect UF to a tone generate then you can play
1.3.1 Connect UF MIDI OUT to tone generator MIDI IN via MIDI cable
1.3.2 Connect tone generator to speaker system, or use head-
phone instead
1.3.3 Switch tone generator HOST SELECT to "MIDI" if there is a
HOST SELECT in the tone generator
1.3.4 Plug AC adaptor's output connector to UF DC IN
1.3.5 Please refer to the figure for connections with Sustain pedal
