CO/Tech MPPH-08CRN1-QB6G1 User Manual

9
ENGLISH
Connecting theexhausthose
Note:
• Theexhaust hose should be used when theCOOL or AUTO functions are selected
in order to divert warm exhaustair.
• Theexhaust hose does not need to be mounted when theFAN or DRY functions
areused.
• Theexhaust hose can be mounted in awindow or asimple temporary set up can
be used to prop up theexhaust hose to discharge theexcess warm exhaustair.
Forpermanent wall installation, refer to theinstructionsbelow.
3. Mark aninstallation hole in thewall using
adapter 4as atemplate. Cutout thehole.
4. Install adapter 4into thehole.
5. Attach adapter 3 to theexhaust hose
and connect thehose to theadapter in
thewall. Close thelid of theadapter when
theexhaust hose is not in use.
6. Make sure that thehose has
therecommended amount of floor
clearance when installing.
7. Do not allow any bends in thehose.
1. Attach adapter 1 to the exhaust hose.
2. Slide thehose’s coupling adapter onto
theexhaust attachment point (6).
