Electrical installation and wiring
4-24 Chapter 4: Installation 98-145168-A
Pin-out for CSDU rear receptacle (top plug)
Table 4-4: Pin allocation for the CSDU top plug
Pin Pin name
TP71 RF TX or RX/TX, to HELGA/HLD
TP01A No connect
TP01B No connect
TP01C ATE pin 3 (Spare GND)
TP01D ATE pin 4
(Spare Discrete Input #5)
TP01E ATE pin 5 (Spare Discrete Output #4)
TP01F ATE pin 6 (Spare Discrete Output #5)
TP01G ATE pin 7 (ATE Pin A Discrete Input)
TP01H ATE pin 8 (ATE Pin B Discrete Input)
TP01J ATE pin 9 (Spare 0V)
TP01K ATE pin 10: (Spare GND)
TP02A Empty Cavity
TP02B Empty Cavity
TP02C Empty Cavity
TP02D ATE pin 14
(Spare Discrete Input #6)
TP02E ATE pin 15
(Spare Discrete Input #7)
TP02F ATE pin 16
(Spare Discrete Output #6)
TP02G ATE pin 15
(Spare Discrete Output #7)
TP02H ATE pin 18: Empty Cavity
TP02J ATE pin 19: Empty Cavity
TP02K ATE pin 20: Empty Cavity
TP03A Ethernet 1 from CSDU to User + (AISD#1)
TP03B Ethernet 1 from User to CSDU + (AISD#1)
TP03C Empty cavity!
TP03D Config Pin 1 (0B Common)
TP03E No Connect
TP03F Config Pin 3 (Program Pin Parity)
TP03G Config Pin 4 (SCM Presence)
TP03H Empty Cavity
TP03J Ethernet 11 from CSDU to User+ (AISD#2)
TP03K Ethernet 11 from User to CSDU+ (AISD#2)
TP04A Ethernet 1 from User to CSDU - (AISD#1)
TP04B Ethernet 1 from CSDU to User - (AISD#1)
TP04C Empty cavity!
TP04D Config Pin 5 (SDU Number)
TP04E No Connect
TP04F No Connect
TP04G No Connect
TP04H Empty Cavity
TP04J Ethernet 11 from User to CSDU- (AISD#2)
TP04K Ethernet 11 from CSDU to User- (AISD#2)
TP05A Empty Cavity
TP05B Empty Cavity
TP05C Empty Cavity
TP05D No connect
TP05E No connect
TP05F No connect
TP05G No connect
TP05H Empty Cavity
TP05J Empty Cavity
TP05K Empty Cavity
TP06A Ethernet 2 from CSDU to User+ (PIESD#1)
TP06B Ethernet 2 from User to CSDU+ (PIESD#1)
TP06C Empty Cavity
TP06D No connect
TP06E No connect
TP06F No connect
TP06G No connect
TP06H Empty Cavity
TP06J Ethernet 12 from CSDU to User+ (PIESD#2)
TP06K Ethernet 12 from User to CSDU+ (PIESD#2)
TP07A Ethernet 2 from User to CSDU- (PIESD#1)
TP07B Ethernet 2 from CSDU to User- (PIESD#1)
TP07C Empty cavity
TP07D No connect
TP07E No connect
TP07F No connect
TP07G No connect
TP07H Empty Cavity
TP07J Ethernet 12 from User to CSDU- (PIESD#2)
TP07K Ethernet 12 from CSDU to User- (PIESD#2)
Pin Pin name
