4.4 Recommended cables
4.4.1 Introduction
This section lists recommended cables and allowed cable lengths for the cables in the
AVIATOR 200S system.
4.4.2 Allowed cable lengths for power cables
Cable type: unshielded
Allowed cable lengths for CSDU
The following table shows the allowed CSDU cable lengths for selected AWG types.
Example for 115 VAC
Requirement for maximum total resistance: 650 m
Selected wire for Line: AWG 16 (14.3 m/m)
Selected wire for Neutral: AWG 12 (5.7 m/m)
Important
For specific cable requirements see the applicable section in 4.3 Electrical
installation and wiring.
Note
It is generally recommended to keep cable lengths as short as possible, specially
on cables for Chassis GND.
Description Pin
Contact
size
Total maximum
resistance (Hot and
cold)
m/m (at 70C)
AWG12 AWG14 AWG16 AWG18 AWG20
115 VAC Line BP1 16 650 m
a
1 -350 m in
circuit breaker
x x 14.3 22.9 36.3
115 VAC Neutral BP5 12 5.7 9 x x x
Chassis BP3 12 25 m
(Max. 1 m)
5.79xxx
x = not suitable for this contact size.
Maximum length
650m
14 3m 57m+m
------------------------------------------------------------- 32,5m==
