Pin-out for CSDU rear receptacle (bottom plug)
Pin Pin name and description
BP1 115 V COLD. 115 VAC power return
BP2 28 V HOT. 28 VDC power (No Connect - Provision only)
BP3 Chassis Ground
BP4 28 V GND. 28 VDC power return (No Connect - Provision only)
BP5 115V HOT. 115 VAC power
BP6
BP7
BP8
BP9
BP10
BP11 BP12
No Connect
