COBHAM SAILOR XTR GX-R2 User Manual

98-175666-C Appendix A: Technical specifications A-2
Specifications SAILOR 1000 XTR GX-R2
A.1 Specifications SAILOR 1000 XTR GX-R2
www.cobhamsatcom.com
SAILOR XTR BELOW-DECK UNIT (BDU)
Dimensions 1U 19” Rack Mount
HxWxD: 4.4 x 48 x 33 cm / 1.
75” x 19” x 13”
Weight 3.6 kg / 8 lb
Temperature (ambient) Operational: -25ºC to +55ºC / -13°F to +131°F
Storage: -40ºC to +85ºC / -40°F to +185°F
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.3 m / 0.7” to EN60945
,QWHUIDFHV [1&RQQHFWRUIRUDQWHQQD5)&DEOHƻ 
with automatic cable loss compensation
 [)&RQQHFWRUVƻIRU5[7[WR96$7 
modem
1 x Ethernet Data (VSAT Modem Control)
2 x Ethernet (User)
1 x Ethernet (Remote access)
 [(WKHUQHWIRU6HUYLFHDQG&RQ¿JXUDWLRQ
1 x RJ-45, RS-422 Data (VSAT Modem Control)
1 x RJ-45, RS-232 Data (VSAT Modem Control)
1 x RJ-45, NMEA 0183 (RS-422 / RS-232) for
Gyro/GPS Compass and external GPS input
1 x RJ-45, 4 x General purpose GPIO, Tx mute
and Rx lock.
1 x Universal AC power input
1 x Grounding bolt
User interface Webserver, OLED display (red), 5 pushbuttons,
 GLVFUHWHLQGLFDWRU/('VDQG2Q2໤VZLWFK7;
Mute and Modem Lock indicator
Temperature control Built-in fan
No transmit zones
Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote management and IoT HTTPS, SSH, Telnet, SNMP Traps, Syslog, CLI,
Diagnostic, Statistic, RESTful, MQTT
VSAT MODEM SUPPORT
Modem protocols Generic, OpenAMIP, OpenBMIP
Modem hardware S
AILOR GX Modem
SAILOR GX MODEM UNIT (GMU)
Dimensions 1U 19” Rack Mount
HxWxD: 4.4 x 48 x 33 cm / 1.
75” x 19” x 13”
Weight 3.5 kg / 7.7 lb
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.3 m / 0.7” to EN60945
,QWHUIDFHV [)&RQQHFWRUVIRU5[DQG7[WR%'8
1 x RJ-45 Ethernet for control and user data,
routes through BDU
1 x RS-422 (Modem Control)
1 x RS-232 Data (Modem Control)
1 x RS-232 Modem console
1 x Universal AC power input
1 x Grounding bolt
Input power
100-240 VAC, 50-60 Hz, 90 W peak, 30 W typical
Modem interface control OpenAMIP, OpenBMIP, RS-422 and RS-232
8VHULQWHUIDFH :HE00,2Q2໤VZLWFKDQGSRZHU/('
Temperature control Built-in fan and heater
SPECIFICATIONS
5HÀHFWRUVL]H FP´
Type appr
ovals Inmarsat
&HUWL¿FDWLRQ &RPSOLDQWZLWK&(0DULWLPH(76,)&&
System power supply range 100-240 VAC, 50-60 Hz
Antenna system power 4.5W: 135W typ. 185W max.
consumption 9.0W: 180W typ. 215W max.
FREQUENCY BAND
Rx 17.7 to 20.2 GHz
Tx 27.5 to 30.0 GHz
ANTENNA CABLE
%'8WR$'8FDEOH &RD[FDEOHI
RU5[7[0R&$DQG'& 
power on a single cable
$'8FDEOHFRQQHFWRU )
HPDOH1&RQQHFWRUƻ
%'8FDEOHFRQQHFWRU )HPDOH1&RQQHFWRUƻ
SAILOR XTR ABOVE DECK UNIT (ADU)
Antenna type, pedestal 3-
axis stabilized tracking antenna with
integrated GNSS supporting GPS, GLONASS and
Beidou
$QWHQQDW\SHUHÀHFWRUV\VWHP 5HÀHFWRUVXEUHÀHFWRUULQJIRFXV
Transmit Gain 47.4 dBi typ. @ 29.5 GHz (incl. radome)
Receive Gain 43.5 dBi typ. @ 19.7 GHz (incl. radome)
6\VWHP*7 G%.W\S#*+]DWHOHYDWLRQ
and clear sky (incl. radome)
GX-R2 transceiver output power 4.5 Watt or 9 Watt
(,53 :G%:LQFOUDGRPH
 :G%:LQFOUDGRPH
LNB Inmarsat GX-R2 transceiver
Polarisation Circular (RHCP, LHCP) independent controlled
for Rx and Tx
Tracking Receiver Internal “all band/modulation type” including
e.g. power, DVB-S2X, GSC and modem RSSI
Satellite acquisition Automatic - with Gyro/GPS Compass input. Sup
port for gyro free operation.
Elevation Range -20° to +120°
Cross Elevation -37° to +37°
Azimuth range Unlimited (Rotary Joint)
Ship motion, angular Roll ±30° (6 sec), Pitch ±15° (5 sec),
Yaw ±10° (8 sec)
Ship, turning rate and acceleration 15°/S and 15°/S2
ADU motion, linear Linear accelerations ±2.5 g max any direction
Vibration, operational Sine: EN60945 (8.7.2), DNV 2.4A, MIL-
STD-167-1 (5.1.3.3.5). Random: Maritime
Vibration, survival Sine: EN60945 (8.7.2) dwell, MIL-STD-167-1
(5.1.3.3.5) dwell.
Random: EN60721-3-6 class 6M3 mod. by
EN60721-4-6
Shock EN60721-3-6 class 6M3 mod. by EN60721-4-6.
MIL-STD-810F 516.5 (Proc. II)
Temperature (ambient) Operational: -25°C to +55°C / -13°F to +131°F
Storage: -40°C to +85°C / -40°F to +185°F
With SAILOR Smart heater option:
P/N: 407090-001 Operational: -55°C to +55°C / -67°F to +131°F
Humidity 95%, condensing
Rain / IP class EN60945 Exposed / IPx6
Wind 80 knots operational, 110 knots survival
Ice, survival 25 mm / 1”
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.5 m / 3.3 lb to EN60945
Maintenance, scheduled None
Maintenance, unscheduled All modules, motor, RF parts and belts are
replaceable through service hatch
Built In Test Power On Self-Test, Person Activated Self-Test
and Continuous Monitoring w. error logging
Dimensions Height: H 150 cm / 58.9”
Diameter: Ø 130 cm / 51.3”
Weight 105 kg / 231 lb
71-177909-A01 01.22
