Settings
98-175666-C Chapter 4: Setup of the antenna 4-13
BDU LAN port 3 - mode
BDU LAN 4 - mode
BDU LAN 5 - Mode:
Static + DHCP server: Used defined Network setup - VLAN 5
ADU LAN 1 - Mode
DHCP client Network parameters obtained via DHCP - VLAN 2
Modem
controlled
User defined VLANS configured by GMU via SNMP
LAN port 1 Modem: LAN Port 3 assigned to LAN Port 1 VLAN / IP-subnet.
LAN port 5 Service: LAN Port 3 assigned to LAN Port 5 VLAN / IP-subnet.
ADU port 1 BDU LAN Port 3 + ADU LAN Port 1 assigned to VLAN 6
Static IP Used defined IP subnet - VLAN 3
DHCP
client
Network parameters obtained via DHCP - VLAN 2
Table 4-8: BDU LAN port 3
LAN port 5 Service LAN Port 4 assigned to LAN Port 5 VLAN / IP-subnet.
ADU port 2 BDU LAN Port 4 + ADU LAN Port 2 assigned to VLAN 7
Static IP Used defined IP subnet - VLAN 4
DHCP client Network parameters obtained via DHCP - VLAN 4
Modem
controlled
LAN Port 1 VLAN's configured by GMU via SNMP
Table 4-9: BDU LAN port 4
Disabled ADU LAN Port 1 disabled.
Service ADU LAN Port 1 assigned to BDU LAN Port 5 VLAN / IP-subnet.
LAN port
3
BDU LAN Port 3 + ADU LAN Port 1 assigned to VLAN 6
Table 4-10: ADU LAN 1
Table 4-7: BDU LAN port 2 (Continued)
