Page 15For technical questions, please call 1-888-866-5797.Item 63890
Mobile Stream
Note: This menu allows you to configure the
settings of a particular channel if the channel
is being viewed via a mobile device.
Figure S
Channel: Choose the channel where
the settings are applied.
Enable: Enable to allow to use mobile
streaming on this channel.
Resolution: Set the resolution.
FPS: This parameter defines the number of
frames per second at the mobile session.
Bitrate Control: Select the bitrate level
based on the complexity of the scene. Refer
to previous two sections for criteria.
Bitrate Mode: If you want to set the bitrate by
yourself, then choose User-defined. If you
want to select the predefined bitrate, choose Predefined.
Bitrate: Enter manually or choose
from the drop-down menu.
Audio: Check box if you want to hear the live
sound at the mobile session. Make sure the
camera with audio capability is properly
connected to the selected channel.
Capture
Note: This menu allows you to configure
the snapshot capturing parameters.
Figure T
Channel: Select the channel to set
its capture parameters.
Auto Capture: Enable or disable automatic
capturing on the channel. When enabled, you
can select the snapshot capturing interval.
Stream Mode: Select the image resolution.
NOTE: When the Auto Capture is enabled, you
can select the image capturing interval.
Normal Interval: Snapshots are captured
based on normal interval.
Alarm Interval: Snapshots are captured based on
alarm interval only when a motion is detected
or sensor is triggered.
Manual Capture: Enable or disable
manual capturing on the channel.
To Next Page
