Page 18 For technical questions, please call 1-888-866-5797. Item 63890
RTSP
Note: The DVR can be remotely viewed
via RTSP protocol. See Figure Z.
Figure Z
RTSP Enable: Enable/Disable
Verify: Enable/Disable
RTSP Port: Default is 554. If default port 554 is
already taken by other applications, please
change it.
Analog Channel: rtsp://IP:Port/chA/B
A: 01(ch1), 02(ch2)….16(ch16)
B: 0(main stream), 1(sub stream)
For example, the DVR IP address is 192.168.1.120,
and you want to view CH1 with mainstream,
then the RTSP address will be:
rtsp://192.168.1.120:554/ch1/0. See Figure BAA.
Figure AA
Note: RTSP user name and password is same with
DVR user name, password and permissions. Follow
the instruction to input IP and port to preview video.
FTP
Note: This menu allows you to enable FTP
function to view and load captured snapshots
from DVR to your storage device over FTP.
Figure AB
FTP Enable: Enable the feature in DVR.
Server IP: Enter your FTP server IP
address or domain name.
Port: Enter the FTP port for file exchanges.
Name/ Password: Enter your FTP
server user name and password.
Directory Name: Enter the default directory
name for the FTP file exchanges.
Test FTP: Click to test the FTP settings.

Cobra 63890 Specifications

General

GPS	Yes
G-Sensor	Yes
Loop Recording	Yes
Channels	1
Remote Viewing	No
Motion Detection	Yes
Night Vision	Yes
Operating System	Not applicable
