Coby PMP-7040 - A;V Input

-
13
-
Connections
A/V Input
The PMP has an A/V input function. Follow the steps below to connect the PMP to
another device, such as a TV.
Plug the 3.5mm plug into the “AV IN” jack on the left side of the PMP.
Plug the RCA plugs into the output jacks of the external device, such as a TV. Be sure
to match up the yellow, red and white plugs with the corresponding jacks. See the
diagram below :
NOTE: In the recording previewing mode, the external A /V signal input will be
displayed on the screen.
