DOOR / WINDOW SENSOR
The Cocoon Wireless Alarm kit comes with 2 entry contact sensors. These can be installed
on doors, windows, drawers or any other object that opens/closes. The sensor will transmit a
signal to the Control Panel when the magnet mounted near the sensor is moved away.
Note: The magnet must be mounted no more than 1cm from the left side of the sensor
to operate.
DOOR / WINDOW SENSOR
LED Indicators
LED ashes once Door/Window has been opened and the transmitter is sending
a signal to the Control Panel.
Solid LED Low voltage indication. Batteries should be changed.
MAGNET
LED INDICATOR
TRANSMITTER
SENSOR FRONT SENSOR BACK
