Product Specications
PARTS LIST:
• 1 x Control Panel
• 4 x PIR (passive infrared) Motion Sensors
• 2 x Door / Window Sensors
• 2 x Swipe Tags
• 2 x Keychain Remote Controls
• 1 x Power Adaptor
• 2 x Rechargeable Batteries (Control Panel)
• 4 x 9V Batteries (PIR Sensors)
• 2 x 23A Batteries (Door / Window Sensors)
• 2 x CR2016 Batteries (Remote Control)
• 2 x Security Stickers
• Mounting Accessories
PRODUCT FEATURES:
• PIR motion sensors to detect intruders
• Door / Window Sensors to detect when
a door or window has been opened or
closed
• Battery operated sensors for easy
installation
• 110dB alarm built into the Control Panel
with provision to add an additional wired
alarm
• Control Panel with built-in rechargeable
batteries for up to 5hrs backup power in
case of power failure
• Supports up to 50 wireless sensors, 10
remote controls and 50 Swipe Tags
• Disarm the system with a swipe of the tag
• 1 million built-in Swipe Tag combinations
for high security
• Voice memo function allows you to record
10 sec voice memos on Control Panel
TECHNICAL SPECIFICATIONS:
Control Panel
Power Supply: DC12V, 1000mA – Only use
the power adaptor provided
Backup Battery: 2x 3.7V, 850mAh Li-Ion
Internal Siren: 110dB
Remote Frequency: 433Mhz
RF operating range: Up to 80m line of sight
Operating Conditions:
- Temperature -10C ~ 55C
- Humidity: <80% (non-condensing)
Dimensions: 188mm x 132mm x 26mm
PIR Motion Sensor Technical Specications
Power Supply: DC 9V Battery
Static Current: <50uA
Alarm Current: <9.5mA
Detection Scope: 8m/110⁰ tested to 8m
RF operating range: Up to 80m line of sight
Remote Frequency: 433Mhz
Detector Dimensions: 105mm x 56mm x
34mm (L x W x H)
Bracket Dimensions: 52mm x 30mm x
26.5mm (L x W x H)
Door / Window Sensor Technical
Specication
Power Supply: DC 12V, 1 x 23A battery
Static Current: <30uA
Alarm Current: <40mA
RF operating range: Up to 80m line of sight
Remote Frequency: 433MHz
Transmitter Dimensions: 68mm x 28mm x
13mm (L x W x H)
Magnet Dimensions: 56mm x 10mm x 10mm
(L x W x H)
