INSTALLING THE CONTROL PANEL
The Control Panel should be placed in an area that is convenient for you to reach as you enter
and exit your home. Before mounting the unit, you should ensure that it is placed within
range of the sensors that are paired with the Control Panel.
WALL MOUNTING
The Cocoon Wireless Alarm Kit Control Panel can be mounted on a wall for easy access.
1. Remove the Control Panel and the Wall Mounting Plate from the packaging.
2. Mark the position where you wish to attach the Control Panel on your wall.
3. Secure the Wall Mounting Plate using the included wood screws.
4. Before attaching to the mounting plate, open the rear cover of the Control Panel to:
a. Connect the power adapter inside the Control Panel.
b. Turn the ON/OFF switch to the ON position.
c. Insert the backup batteries (2x Li-Ion rechargeable batteries)
5. Position the power cable so it exits the battery compartment at the top of the
Control Panel.
6. Replace the back cover of the Control Panel.
7. Attach the Control Panel to the wall mount by sliding into place.
Note: The Wall Mounting Plate will depress the anti-tamper switch. In the event the
Control Panel is removed from the wall, the siren will be triggered.
IMPORTANT: ALWAYS TEST ALL COMPONENTS ARE WORKING PRIOR TO
PERMANENTLY INSTALLING
