Pairing the Door / Window Sensor to the Control Panel
1. Enter your PIN then press the
button.
2. Within 15 seconds, trigger the Door / Window Sensor, by separating the magnet
from the sensor (the Door / Window Sensor’s LED light will ash).
3. The Control Panel will beep to indicate the Door / Window Sensor is now registered
to the Control Panel.
4. Press the
button to enter Armed Mode and test the Door / Window Sensor by
separating the magnet from the sensor. When the alarm sounds, the keypad will
ash one number, showing which sensor has been tripped.
5. Enter your PIN or use your Swipe Tag to enter Disarmed Mode.
6. Repeat this process for other Door / Window Sensors you wish to add to your
security system.
Note: The Door/Window Sensor will rst be activated when the magnet is placed near
the sensor. If you arm the control panel while your door is open it will not become active
until the door is shut.
Replacing the Battery
The Door/Window Sensor comes with 1 x 23A battery pre-installed in the unit.
This will need to be changed when the battery is running low, refer to page 19 for further
information.
1. Open the battery tab on the right side of the sensor
2. Remove the old battery
3. Insert a new 23A battery, taking note of the correct polarity
4. Replace the battery cover
