TN761 Stratus Fixed Infrastructure Radio System
MT-4 Radio Systems
TECHNICAL NOTES
Page 2 of 4
LMRSALES@CODANCOMMS.COM
CODANCOMMS.COMTECHNICAL NOTE:
TN761, REV 1-0-0, © Aug 2016
CANADA/US +1 250 382 8268 | TOLL FREE +1 800 664 4066
The Stratus Fixed Link Infrastructure includes the following:
• 2 RU (rack unit) harware mounting shelf.
• 6 to 34 VDC input power supply.
• 2 N-type 3G/4G LTE Antenna connectors (2nd connector is for a diversity antenna).
• 2 690 - 2700 MHz 3G / 4G LTE wall-mount omni-directional groundplane independant antennas (2 dBi gain).
• SMA connector for Wi-Fi antenna.
• BNC connector for GPS antenna (future capability).
• 4-port ethernet switch.
• cellular modem.
• front panel power LED.
Part numbers for the Stratus Fixed Infrastructure are as follows:
LMR-STRATUS-FPXXX Stratus Fixed Link with MT-4E radio system (30 Watt P25 capable system)
LMR-STRATUS-FIXUP Stratus Fixed Link upgrade to existing MT-4E radio system
The Stratus
Fixed Link Infrastructure is 19” rack mountable, 2 RU (3.5” / 8.8 cm) high and 7.5” (19 cm) deep, and
weighs 10.5 lbs. (4.6 kg).
The Stratus cellular modem is carrier specifi c and is also available with optional Wi-Fi capability The modems
operate on carriers and Wi-Fi as follows:
CI-MODEM-01 Telus / Bell / Rogers CI-MODEM-W1 Telus / Bell / Rogers (Wi-Fi capable)
CI-MODEM-02 AT&T CI-MODEM-W2 AT&T (Wi-Fi capable)
CI-MODEM-03 Verizon CI-MODEM-W3 Verizon (Wi-Fi capable)
CI-MODEM-04 International CI-MODEM-W4 International (Wi-Fi capable)
CI-MODEM-05 Sprint CI-MODEM-W5 Sprint (Wi-Fi capable)
