Codan MT-3 User Manual

TN761 Stratus Fixed Infrastructure Radio System
MT-4 Radio Systems
TECHNICAL NOTES
Page 3 of 4
LMRSALES@CODANCOMMS.COM
CODANCOMMS.COMTECHNICAL NOTE:
TN761, REV 1-0-0, © Aug 2016
CANADA/US +1 250 382 8268 | TOLL FREE +1 800 664 4066
The Stratus Fixed Link case with the lid removed is shown in Figure 1. This shows how cellular modem, ethernet
switch and power supply are mounted inside of the Stratus Fixed Link case.
Figure 1: Stratus Fixed Link case with case lid removed
Stratus Fixed Link Infrastructure includes two 3G / 4G LTE waterproof omni-directional groundplane independant
antennas with 2 dBi of gain. These antennas include a steel zinc plated fi nish L-Bracket for wall mounting. The
antennas have N-Female connectors and a white UV-resistant sheath.
Figure 2: 3G / 4G LTE omni-directional antennas
ETHERNET
SWITCH
CELLULAR MODEM
GPS & WI-FI
ANTENNA
CONNECTORS
ETHERNET
JACKS
POWER
DISTRIBUTION
CELLULAR
ANTENNA
CONNECTORS
POWER
SWITCH &
SOURCE
