Installation
52 NGT Transceiver Getting Started Guide
Connecting the control cable to an automatic tuning
antenna
To connect the control cable to an antenna:
1 Connect the socket at the end of the cable into the plug
at the base of the antenna, then secure the locking ring
tightly into position.
1 Fit the plug at the opposite end of the cable into the
socket at the end of the lead from the RF unit.
Connecting the power supply
To connect the transceiver to the battery power supply:
1 If you are using a 24 V battery supply, connect the
battery to a 24 V to 12 V voltage regulator (Codan part
number 15-00508).
1 Connect the power supply cable (Codan part number
08-03255) to the plug at the end of the 12 V cable lead
from the RF unit.
1 Route the power supply cable according to the
instructions supplied with the Vehicle Installation Kit
(Codan part number 15-00112).
1 Insert the 32 A fuse and holder in the power supply cable
at a convenient location, as close as possible to the
battery terminals.
1 Connect the power supply cable to the battery terminals,
black to negative, red to positive.
Connecting ancillary equipment
The NGT AR and SR Transceiver mobile systems use the
junction box for connecting to ancillary equipment.
The 6-way connector on the RF unit of the mobile
NGT AR Voice Transceiver is available for connecting a GPS
receiver.
