Codan NGT AR User Manual

Installation
58 NGT Transceiver Getting Started Guide
Connecting a fixed NGT station
Connecting a fixed NGT AR or SR station
To connect a fixed NGT AR or SR station:
1 Connect the socket at the end of the cable to the plug
at the end of the cable lead from the RF unit, then
secure the locking ring tightly into position.
1 Connect the socket at the opposite end of the cable to
the plug at the rear of the desk console, then secure
the locking ring tightly into position.
1 Connect the plug at the end of the cable to the socket at
the end of the cable lead from the RF unit, then secure
the locking ring tightly into position.
1 Connect the plug at the opposite end of the cable to the
socket located at the base of the antenna, then secure the
locking ring tightly into position.
NOTE
The handset is supplied connected to the desk
console (Codan part number 15-10471).
