Save Settings
1.6.4.1 - Additional RS-232 (Serial) Communication Data Bit Settings
Scan the following codes to set the appropriate data bit:
7 Data Bits 8 Data Bits (Default)
1.6.4.2 - Additional RS-232 (Serial) Communication Baud Rate Settings
Scan the following codes to set the appropriate baud rate:
1200 2400 4800 9600
19200 38400 57600 (Default) 115200
1.6.4.3 - Additional RS-232 (Serial) Communication Parity Settings
Scan the following codes to set parity:
Even Odd None (Default)
1.6.5 - Cabled Reader - Time Out Settings
Scan one of the codes below to set the amount of time a cabled CR2 will be enumerated before entering sleep mode in
order to more quickly charge the battery:
Note: These settings will only work in versions 2098 and above.
Cabled Reader Time Out: 2 hours Cabled Reader Time Out: Never (Default)

Code Reader 1200 Specifications

General

Brand	Code
Model	Reader 1200
Category	Barcode Reader
Language	English
