14 OPERATORS MANUAL VITRO LINE
THE BEVERAGE MACHINE MUST BE EARTHED.
VITRO ā S2/S3/X3/X4 / Bean to Cup / DUO / Espresso
The beverage machine is fitted with a domestic 3 pin plug for connection to a standard 13A
supply, alternatively, the beverage machine may be connected via a safety isolator switch
with a contact separation of at least 3mm, to a 230V~, 50Hz, 13A supply. Note that
replacement of the Y Type mains cable requires special tools. Should the cable become
damaged, replacement must only be carried out by a trained person from an approved
service agent.
To reconfigure the machine to operate from a 110V supply, move the voltage selector link
on the PSU to the 110V position and replace the 240V 3kW element (part no. 12345) with
a 110V 1.6kW element (part no. 56223).
VITRO ā S4 Instant
The mains cable fitted to the machine should be 3-core, 4-core or 5-core, depending on the
electrical supply available and the number of heaters to be connected in circuit. The cable is
terminated at a terminal block at the base of the machine. Connection to the electrical supply
must not be carried out using a cable with more cores than required, e.g. do not use a 5-core
cable in place of a 4-core cable, etc.
Do not attempt to connect all three heaters to a 230V~ single phase supply. Similarly, do not
attempt to connect more than one heater to a 230V~, 10A or 16A single phase supply. The
mains cable must be connected to the supply via a safety isolator switch, preferably located
behind the machine. Ensure that the supply to the isolator switch is isolated before making
the connections. Ensure that the supply to the beverage machine is isolated before making
any connections to the terminal block. The machine must be earthed.
Connect the beverage machine, via a safety isolator switch with a contact separation of at
least 3mm, to a 230V~, 50Hz, 13A supply. Note that replacement of the Y Type mains cable
requires special tools. Should the cable become damaged, replacement must only be carried
out by a trained person from an approved service agent.
Changing the electrical configuration of a Vitro S4 Instant including its mains supply chord
requires special tools and training. It should only be undertaken by suitably qualified persons.
Preferably, the isolator switch should be located behind the machine to prevent accidental
damage or misuse
