13 OPERATORS MANUAL VITRO LINE
Connecting The Water Services
Only to the UK: Refer to the current requirements of The Model Water Bylaws
1986
Statutory Instrument (SI) No.1147.
The water supply should be taken from a 15mm rising main at a pressure of between 100 kPa to
800 kPa and should be fitted with a stopcock to isolate the supply during servicing. A 15mm
double back check valve, with inspection port, should be fitted to the flexible hose.
A Water Blocker must be fitted to the main water supply
The outlet should be fitted with appropriate connections, standard in every country, and must be
positioned within 1.5m of the machine to ensure correct fitting of the hose. If possible, the outlet
should be located behind the machine to prevent misuse.
Before connecting the machine hose to the mains outlet, flush the system, via the stopcock, to
remove any impurities that may have accumulated in the mains supply pipe.
Connect the machine hose to the mains outlet using the seals supplied and ensure that all fittings
are tight. Turn on the water supply at the stopcock and check for leaks, both behind and inside
the machine.
Connecting the Electrical Services
WARNINGS THE MACHINE MAINS CABLE MUST BE CONNECTED TO THE SUPPLY
VIA A SAFETY ISOLATOR SWITCH WHICH PROVIDES A CONTACT
SEPARATION OF AT LEAST 3mm.
REPLACEMENT OF THE Y TYPE MAINS CABLE REQUIRES SPECIAL
TOOLS. SHOULD THE CABLE BECOME DAMAGED, REPLACEMENT
MUST ONLY BE CARRIED OUT BY A TRAINED PERSON FROM AN
APPROVED SERVICE AGENT.
ENSURE THAT THE SUPPLY TO THE ISOLATOR SWITCH IS ISOLATED
BEFORE MAKING ANY CONNECTIONS TO IT.
ENSURE THAT THE SUPPLY TO THE BEVERAGE MACHINE IS
ISOLATED BEFORE MAKING ANY CONNECTIONS TO THE TERMINAL
BLOCK AT THE REAR OF THE MACHINE.
IF THE EQUIPMENT WAS SUPPLIED WITH A MAINS WATER HOSE, THIS
HOSE SHOULD BE USED. DO NOT USE A HOSE FROM A PREVIOUSLY
INSTALLED PRODUCT EVEN IF IT WOULD FIT. TO DO SO COULD LEAD
TO A HEALTH HAZZARD.
