3 Install the Wafer Reader

In this Section…

3.1 Verify Required Hardware Components........................................ 11

3.2 Attach the Mirror for Horizontal Operation (Optional) .................... 12

3.3 Mount the Wafer Reader............................................................... 13

3.4 Connect the Network and Breakout Cables .................................. 15

This section describes the connection of the wafer reader to its standard and optional

components. For a complete list of options and accessories, contact your Cognex sales

representative.

3.1 Verify Required Hardware Components

• In-Sight 1720 Series Wafer Reader

• 24VDC Power Supply and Adapter

• Network Cable

• Breakout Cable

• Mirror for Horizontal Operation (Optional)
