SECTION 1: GENERAL INFORMATION
INTRODUCTION
This manual contains information on installing, operating
and maintaining Coinco's BA30 Series bill acceptors.
This manual is intended for owners, route operators and
shop-level technicians as a primary source of informa-
tion. Taking time to read this manual and becoming
familiar with this information will help you obtain the
best performance from your Coinco bill acceptor.
MODELS
BA30 Series bill acceptors are self-contained units
designed to work with existing vending machine inter-
faces, plus MDB vendors. Listed below are some of the
models available:
BA30B Bill Acceptor, 300 capacity stacker, 110VAC,
Bottler interface and mask
BA32B Bill Acceptor, 300 capacity stacker, 24VAC,
Bottler interface and mask
BA50B Bill Acceptor, 500 capacity stacker, 110VAC,
Bottler interfance and mask
BA30SA Bill Acceptor, 300 capacity stacker, 110VAC,
Snack interface and mask, Additional length
harness
BA32SA Bill Acceptor, 300 capacity stacker, 24VAC,
Snack interface and mask, Additional length
harness
BA92T Bill Acceptor, 950 capacity stacker, 24VAC,
Ticket vendor interface and mask
BA30B bill acceptors are primarily used in cold drink
vendors which use either the electromechanical, elec-
tronic, or MDB interface. This bill acceptor uses the
"bottler" interface, which communicates to the vendor
through either HIGH LEVEL or MDB communication.
BA30SA and BA32SA bill acceptors are primarily used
in either electronic or MDB snack, coffee or food ma-
chines. These bill acceptors use the "snack" interface and
communicate to the vendor through either PULSE,
SERIAL, PARALLEL or MDB communication.
FOR YOUR RECORDS
A label indicating the model number and serial number is
affixed to the back of the bill acceptor. Refer to the
model and serial number whenever you call upon your
Coinco Service Center for information or service. The
first four digits of the serial number contain the manufac-
turing date code which indicates the beginning of the
warranty period.
EXAMPLE: Serial number 269700135. First and
second digits indicate the week of manufacture. The
third and fourth digits indicate the year (the 26th week
of 1997).
FEATURES
• Modular design
• State-of-the-art electronic logic system
• Switch selectable acceptance of the following bills: $1,
$2, $5, $10 and $20.
• High capacity bill box.
• Vandal resistant design protects against: saltwater, bill
pullback, counterfeit bills.
• Utilizes standard mounting and electrical interfaces.
• 110 and 24 VAC and 24 VDC Multi-Drop Bus
interfaces available.
• High impact, non-corrosive plastic construction.
• Easily accessible bill path.
• Self-diagnostics communicated via status light.
• Standard/High Level security switch.
• Switch selectable acceptance of bills face up, in one or
both directions.
• Optional non-resettable counter.
• Optional hasp for locking bill box.
• Manufactured and supported by Coinco.
• Made in the U.S.A.
AFTER UNPACKING
After unpacking the unit, inspect it for any possible
shipping damage. If the unit is damaged, notify the
shipping company immediately. Only the co-signee (the
person or company receiving the unit) can file a claim
against the carrier for shipping damage. We recommend
that you retain the original carton and packing materials
to reuse if you need to transport or ship your acceptor in
the future.
If the bill acceptor is being stored or used as a spare,
always keep it in its shipping carton when not in use.
This will keep it clean and offer the best protection for
the unit.
