SECTION 1: GENERAL INFORMATION
MAIN LOGIC BOARD ASSEMBLY
The main logic board contains the microprocessor which
controls all the functions of the bill acceptor based on
information from the vending machine, coin mechanism
and various bill acceptor sensors.
Also contained on the main logic board is the power
supply which receives its primary voltage from the
vending machine. For 117VAC units, the primary AC
voltage is routed to the transformer in the bill acceptor
where it is reduced to 24VAC. This 24VAC is then
routed back to the main logic board where it is rectified
and filtered for logic board operation. For 24VAC and 24
VDC (MDB) units, no transformer is needed. The
primary voltage is rectified and filtered on the main logic
board.
SPECIFICATIONS
Power Requirements
BA30B, BA30SA — 117VAC
95 to 130 VAC, 60 Hz
0.2 Amp max standby
0.75 Amp max operating
BA32B, BA32SA — 24VAC
20 to 32 VAC, 60 Hz
0.2 Amp average standby
2.5 Amp average operating
All MDB — 24VDC
22 to 45 VDC
0.2 Amp average standby
2.5 Amp average operating
Operating Temperature
32°F to 150°F
0°C to 65°C
Storage Temperature
-22°F to 165°F
-30°C to 74°C
Relative Humidity
5% to 95% non-condensing
Physical Weight in Shipping Carton
5.7 pounds - 117VAC
4 pounds - 24VAC
Physical Dimensions
BA30 BA50 BA70
Height 11.53 inches 11.53 inches 11.53 inches
from top of bill box to bottom of mounting plate
Width 5.31 inches 5.31 inches 5.31 inches
from logic board cover to mounting plate
Depth 4.27 inches 4.90 inches 5.52 inches
from mounting plate to back of stacker
