SECTION 2: INSTALLATION
BA30SA/BA32SA Option Switch Settings
(see Figure 2)
SWITCH ON OFF
1 High Security Standard Acceptance
2 Accepts bills in one Accepts bills in both
directions only (face directions (face up)
up, green seal first)
3 Serial or Parallel Pulse Interface
Interface
4 $20 Accept $20 Reject
5 $10 Accept $10 Reject
6 $5 Accept $5 Reject
7 $2 Accept $2 Reject
8 $1 Accept $1 Reject
BA30B/BA32B Option Switch Settings
(see Figure 2)
SWITCH ON OFF
1 High Security Standard Acceptance
2 Accepts bills in one Accepts bills in both
directions only (face directions (face up)
up, green seal first)
3 Standard credit pulse Short credit pulse
150ms on 150ms off 50 ms on 50 ms off
4 $20 Accept $20 Reject
5 $10 Accept $10 Reject
6 $5 Accept $5 Reject
7 $2 Accept $2 Reject
8 $1 Accept $1 Reject
INSTALLING THE BILL ACCEPTOR
1. Remove power from the vending machine.
2. Set the bill acceptor option switches as desired.
3. Mount the bill acceptor according to the instructions
found in the vending machine manual or appropriate
kit literature.
4. Connect the bill acceptor harness to the mating
harness in the vending machine.
5. Load the vending machine with product and fill the
coin changer with change.
6. Apply power to the vending machine.
7. Test for proper operation.
