Page 10 800 Series
SECTION 3: CONFIGURATION
Option Switch Module
Single-Price/Four-Price Models Only
Located behind the acceptor on the middle right
hand side of the changer housing are twelve
switches (see Figure 2). The first eight are used
to set the vend price (see “Setting The Vend
Price” section of this manual).
The last four Option Switches are used to enable
or disable the following options:
Note: The swiches are ON in the upwards
position.
Switch A (SW9)
Controls whether the escrow feature of the
changer is inhibited.
ON Escrow inhibited.
OFF Escrow not inhibited.
Switch B (SW10)
Determines the operation mode of the changer.
ON Operates as a Four-Price changer.
OFF Operates as a Single-Price changer.
Switch C (SW11)
(Single-Price Mode Only)
Controls the vend holding feature.
ON Vend is held until selection is made.
OFF Vend is pulsed.
Switch D (SW12)
Controls when the changer enters the “Use
Correct Change” condition.
ON Uses the sum of the highest price plus
the value of the highest coin for the
“Use Correct Change” indicator.
OFF Uses a programmable value for
“Use Correct Change” indicator.
“Use Correct Change” indicator is
illuminated when changer is unable to
make change for the programmed value
or any lesser value.
