Coinco GLOBAL2 - Installation Diagrams

Page 7
800 Series
VEND
MOTORS
DIGITAL
DISPLAY
SELECTION
SWITCHES
VENDING MACHINE
CONTROLLER
POWER
SUPPLY
SHIELD
TX-
RX+
TX+
RX-
9
4
3
1
2
P2
P1
2
9
1
EXACT CHANGE
24 VAC
24 VAC
EXECUTIVE COIN
CHANGER
(E.G. GBP-A801C)
VEND
MOTORS
DIGITAL
DISPLAY
SELECTION
SWITCHES
VENDING MACHINE
CONTROLLER
(MDB MASTER)
POWER
SUPPLY
CHANGER
(MDB Slave
Peripheral)
1
2
3
4
6
5
Master Receive
Master TX
Comms Gnd
Supply Gnd
+ve supply
P1
Other MDB Slave
Devices. E.g. Key
reader, Bill validator,
Audit device etc.
MDB SERIAL
COMMS BUS
Other MDB Slave
Devices. E.g. Key
reader, Bill validator,
Audit device etc.
Figure 5 - MDB Interface
SECTION 2: INSTALLATION
P1 - MDB Slave
Connector
Figure 6 - Protocol A (Executive) Interface
1
9
2
P2 - Protocol A Data
Connector
P1 - Protocol A
Data Connector
P2 - Protocol A
Data Connector
P1 - Protocol A Power Connector
