Coinco GLOBAL2 - SECTION 6: EXPLODED VIEWS Exploded Views

Page 31
800 Series
SECTION 6: EXPLODED VIEWS
138.9
66.5
61.5
68.3
25.2
3X 6.4
3X 9.7
335.3
114.1
3x 4.8
37.3
138.9
68.3
61.72
8.9
58.4
R173.0
MAXOPENING
76.2
40.1
36.8
10.4
8.6
89.2
83.1
53.6
33.0
7.4
4.8
36.1
40.1
COIN RETURN
AREA
COINPAYOUT
AREA
CASHBOX
CHUTEAREA
20.3
11.7
16.3
358.6
INT’L
LEVER
800 Series Dimensional View
ALL MEASUREMENTS ARE SHOWN IN MILLIMETERS
