Page 30 800 Series
TROUBLE POSSIBLE CAUSE PROCEDURE REMEDY
Accepted Coins Always Coin Routing Check that coins are routed to tubes. See “Rerouting the Coins.”
Go To Cashbox
Tube Sensor Board Check the sensor board for loose Replace tube sensor board.
or Acceptor components. Make sure tube
sensor board is properly secured
to main logic board. Check cable
from sensor board for damage or
improper connection.
If coin still goes to cashbox, replace Replace acceptor.
acceptor with good acceptor and test
to see if changer functions properly.
If coin still goes to cashbox, Replace changer’s main
logic board.
Accepted Coins Always Coin tube gate is in Remove acceptor back cover Replace acceptor.
Go To Coin Tubes the open position and check solenoid for free
operation.
Tube Sensor Board Replace tube sensor board with Replace tube sensor board.
good board and test to see if
changer functions properly.
If coins still go to tubes, Replace changer’s main
logic board.
Changer Credits Coins Coin return lever Make sure changer is mounted Reposition changer and/or
But Does Not Escrow correctly and acceptor gate opens vendor coin return lever.
when vendor coin return lever is
operated.
Acceptor Replace acceptor with good Replace defective acceptor.
acceptor and test to see if
changer operates correctly.
Switch 9 is ON - escrow is Uninhibit the escrow feature. Turn switch 9 OFF and press
inhibited. the Mode Switch.
No Payout Payout Motor Make sure motor wires are Plug motor wires into
properly connected to changer’s logic board.
main logic board.
If still no payout, replace motor Replace defective
with good motor and test to see if payout motor.
changer operates properly.
SECTION 5: TROUBLESHOOTING
Troubleshooting Guide
