Coinco GLOBAL2 - Page 8

Page 8 800 Series
Neutral
Live
Blocker
9
4
3
1
2
P1
2
9
1
Exact Change
Vend Line 1
EXECUTIVE COIN
CHANGER
(E.G. GBP-F811)
Vend Line 2
Vend Line 3
Vend Line 4
Selection switch
LiveVend Motor
M
Neutral
Vend Relay
Typical Vending machine vend line wiring, Only to be
used as an example.
P1- Jones Plug
VEND
MOTORS
DIGITAL
DISPLAY
SELECTION
SWITCHES
VENDING MACHINE
CONTROLLER
POWER
SUPPLY
SHIELD
TX-
RX+
TX+
RX-
9
4
3
1
2
P2
P1
2
9
1
EXACT CHANGE
24 VAC
24 VAC
EXECUTIVE COIN
CHANGER WITH
MDB MASTER
(E.G. EUR-A901B)
MDB CASHLESS
DEVICE OR BILL
ACCEPTOR
1
2
3
4
6
5
Master Receive
Master TX
Comms Gnd
Supply Gnd
+ve supply
P3
SECTION 2: INSTALLATION
Figure 7- Protocol A (Executive) Interface with MDB Master Support
P3 - MDB Master
Connector
1
9
2
P2 - Protocol A Data
Connector
P1 - Protocol A
Data Connector
Figure 8 - Four Price Electro-Mechanical Interface
P2 - Protocol A
Data Connector
P1 - Protocol A
Power Connector
