Page 20 800 Series
Address Field Description G S/F A BDV
C001 Prices 1 (Repeated at address C101) Value N Y Y N
C002 Prices 2 (Repeated at address C102) Value N Y Y N
C003 Prices 3 (Repeated at address C103) Value N Y Y N
C004 Prices 4 (Repeated at address C104) Value N Y Y N
C005 Prices 5 (Repeated at address C105) Value N N Y N
C006 Prices 6 (Repeated at address C106) Value N N Y N
C007 Prices 7 (Repeated at address C107) Value N N Y N
C008 Prices 8 (Repeated at address C108) Value N N Y N
C009 Prices 9 (Repeated at address C109) Value N N Y N
C010 Prices 10 (Repeated at address C110) Value N N Y N
C011 Maximum change paid out in Value N N Y N
Multivend mode
C012 Discount award (Increase in credit Value N N Y N
when discount trigger is reached)
C013 Discount Award Trigger Value N N Y N
C014 Exact Change Accept Group Single/Four-Price (Electromechanical) N Y N N
Displays MDB coin type number – Coins
up to and including this value will be
accepted when there is an Exact Change
condition.
Executive (Protocol A):
Coin Value reported - Coins up to and including N N Y N
this value will be accepted when there is an
Exact Change condition.
C015 Single/Multivend and Single/Four-Price (Electromechanical): N Y N N
Cashless Revaluation 0 Multi Vend Disabled
1 Multi Vend Enabled
Executive (Protocol A): N N Y N
Card Revaluation OFF:
0 Single-vend, Credit Limit
1 Multi Vend, Credit Limit
2 Single Vend, Price Limit
3 Multi Vend, Price Limit
Card Revaluation ON:
4 Single vend, Credit Limit
5 Mulit Vend, Credit Limit
6 Single Vend, Price Limit
7 Mulit Vend, Price Limit
C016 Escrow Return Inhibit 0 Coin Return Allowed N Y Y N
1 Coin Return NOT Allowed
C019 Peripheral and Clear Checksum Flag No Executive Card Reader N Y Y N
0 Checksum OK
1 Checksum Error
Executive Card Reader Installed
4 Checksum OK
5 Checksum Error
C020 Bill Value (scaled) Value N Y N N
C021 Four Price Time out Programmable 4-20 seconds N Y N N
SECTION 3: CONFIGURATION
Y=Supported
N=Not Supported
R=Read Only
DIGITAL DISPLAY
AUDIT INFORMATION CHANGER ADDRESSES
