Page 22 800 Series
Display Description Options
Addresses
A001 Select Unit Configuration, 1 Enables and pays out coins 16-31
applicable to Dual Currency 2 Enables coins 0-31, pays out coins 16-31
models only. 3 Enables coins 0-31, pays out coins 0-15
4 Enables and pays out coins 0-15
Note: The reported currency will be that of the coins
being paid out
A002 Payout Configuration * Used to select a standard payout configuration or for
a user payout configuration. ALT options are user programmable.
A003 Tokens Enabled (If tokens 0 Disable all tokens
are programmed) 1 Enable all tokens
A004 Coin Ratio (read only) * Displays the coin values
A005 Coin Enables * 0 Coin is disabled
1 Dummy MDB coin.
2 Coin accepted, Non-compressed for MDB
3 Coin accepted, Compressed for MDB
The following can only be set in the factory:
4 Slug Eater
5 Slug Eater with dummy coin
6 Credited and Returned, Non-compressed
7 Credited and Returned, Compressed
A006 Validation Acceptance Level * Relative acceptance Levels (1-10) for all 32 coin types
1 Highest slug protection
~
7 Factory acceptance rate
~
10 Highest acceptance rate
A007 Float Setting - All Tubes Each Digit Represents a Tube “A-B-C-D”
0 Float mode disabled
1 Float level set
2 Float pay-down set
A008 Float Setting - Individual Tubes* 0 Float mode disabled
1 Float level set
2 Float pay-down set
A009 Alternative Payout 0 Disable Enhanced coin payout
1 Enable Enhanced coin payout
A010 Scaling Factor Value used to scale all coins
A011 Decimal Point Value (read only) Value
A012 Remainder Enable 0 Remainder disabled
Applicable to Dual Currency 1 Remainder enabled, never cleared
models only 2 Remainder enabled, cleared at reset
3 Remainder enabled, cleared at payout
4 Remainder enabled, cleared at reset or payout
SECTION 3: CONFIGURATION
DIGITAL DISPLAY
GENERAL USE ACCEPTOR INFORMATION ADDRESSES
* Indicates a sub-address is used
