Page 24 800 Series
SECTION 3: CONFIGURATION
Example of changing the
predefined coin routings.
To configure the coin tubes via the Digital
Display, follow these steps:
1. Enter the Display Mode (see “Display
Mode” section of this manual).
2. Press B to scroll up to the Address “A002”
3. Press C to enter the Address.
4. Use buttons B (increase) or D (decrease) to
change selection to “802”.
5. Press C to enter the new routing information.
The far right decimal point will illuminate to
indicate the selection has been stored.
6. Press A to return to the Address Display.
7. Press A to exit the Display Mode. The
payout configuration has been changed to
“802”.
EXAMPLE: The COINCO GLOBAL® changer is
configured as follows:
Coin Type 0 goes to Tube A
Coin Type 1 goes to Tube B
Coin Type 2 goes to Tube C
Coin Type 3 goes to Tube D
Remaining Coin Types 4-15 go to Cashbox.
BUT, Coin Type 6 is interchangeable with coin type 0 and
must be accepted to Tube A along with coin type 0 . . .
Example of setting up user
defined coin routing.
1. Enter the Display Mode.
2. Press B to scroll up to Address “A002”.
3. Press C to enter the Address.
4. Press B (increase) or D (decrease) to choose
one of the programmable payout configura-
tion selections.
5. Press C to select the payout configuration.
6. Press C again to enter programmable payout
configuration mode. The display will be
shifted to the far left.
7. Use button B and D to choose tube A (“A“ on
the display) then drop one of coin type 0 and
one of coin type 6.
8. Select tube B, drop one of coin type 1.
9. Select tube C and drop one of coin type 2.
10. Finally, Select tube D drop one of coin type
3.
11. Verify all coins have been routed to the
desired tubes.
12. Press A to return to address menu
13. Press A again to exit. The payout configura-
tion has now been changed to:
Coin Type 0 goes to Tube A and cashbox
Coin Type 1 goes to Tube B and cashbox
Coin Type 2 goes to Tube C and cashbox
Coin Type 3 goes to Tube D and cashbox
Coin Type 6 goes to Tube A and cashbox
Coin Types 4,5 and 7-15 go to Cashbox only
