Colorlight Z6 Super Controller User Manual

17
6.2 Main Interface
After starting the controller, main interface of LCD display is as follows:
First row: Company name.
Second row: Signal source and resolution of main image, brightness.
Third/forth row: Connection status of signal source and Genlock, 10bit mode on/off.
Fifth row: Connection status of network port.
Sixth row: Product type, the IP of Z6.
6.3 Operation Instruction
Press the knob/OK to enter the operation interface of main menu, and it includes 11
operation instructions: Display Setting, EDID Setting, Splicing Setting, Input Clip Setting, Output
Setting, Output Shift, Lock to Input, Art-Net Setting, Network Setting, Language Setting, System
Setting.
6.3.1 Display Setting
Rotate the knob to select display setting, then press the knob/OK to enter submenu of
“Display Setting”.
