Colorlight Z6 Super Controller User Manual

1
1 Ove
rview
Z6 Super Controller is a professional LED display controller. As video splicer, processor and
sender in one combined, Z6 has 4K video input capability, UHD and HDR images processing and
transmission. Z6 can be applied to high-end rental display and high resolution LED display perfectly.
Features:

Video input ports including SDI×2, HDMI2.0×1, DVI×4;

Support input resolution up to 3840×2160@60Hz;

Loading capacity: 8.3 million pixels, Maximum Width/Height: 8192 pixels;

The input images can be spliced and scaled according to the screen resolution;

Support PIP function, the location and size can be adjusted freely;

Support splicing and cascading among several controllers with synchronization strictly;

Support 3D display;

Support brightness and chromaticity adjustment;

Support improved gray-scale at low brightness;

Support HDCP2.2；

Compatible with all receiving cards, multifunction card, optical fiber transceivers of Colorlight.
2 Appearance
Front Panel
NO Name Fu
nction
1 3.5-inc
h LCD Display operation menu and system information
2 K
nob Turning knob to select or adjust
