Colorlight Z6 Super Controller User Manual

2
3 Fu
nction keys
OK：Enter key
ESC: Escape current operation or selection
Bright: Brightness options
Black: Blank screen
Lock: Lock keys
4 Select
ion keys
PIP: PIP switch
Freeze: Freeze screen
DVI/HDMI/SDI1/SDI2: video source selection
Back Panel
In
put Interface
1 SD
I 2 3G-SDI inputs
2 HDMI HDMI2.0 input
3 D
VI 4 DVI inputs
O
utput Interface
1 Gig
abit Ethernet 16 Neutrik Gigabit Ethernet outputs
Con
trolling Interface
1 100M
Ethernet
100M-Ethernet Control port (communication with PC, or access
network), and can be used as Art-Net control port
2 US
B_OUT USB output, cascading with next controller
3 USB_IN USB input, connecting to PC to configure parameters
4 Genlo
ck Genlock signal input ensures synchronism of display image
5 Genlo
ck_loop
Genlock synchronous signal loop output
6 3D s
ync
Connect to 3D emitter (Optional)
