SYMBOLS USED ON THE MACHINE
Indicates the general switch
Indicates the exhaust pipe of the recovery tank
Symbol denoting cock
Indicates the cock lever
Indicates the solenoid valve switch
Symbol denoting up-down brushes base
Indicates the lever of the brushes base lifting
Symbol denoting up - down of the squeegee
Indicates the squeegee lever
Symbol denoting the brushes pressure
Symbol denoting brush
Indicates the switch of the brushes control
Symbol denoting suction motor
Indicates the suction motor switch
Symbol denoting charge level of the batteries
Symbol denoting brake
It is used on top of the emergency and parking brake lever
Symbol denoting brake
It is used to indicate the signal lamp of the hand brake
Indication of the maximum temperature of the solution detergent
Placed near the charging hole of the solution tank
