9
MACHINE PREPARATION
1. HANDLING OF THE PACKED MACHINE
The machine is packed in a specific package provided on a pallet for the handling with fork trucks. The
packages cannot be placed on top of each other.
The total weight is:
1. 277 kg per la OMNIA26
2. 312 kg per la OMNIA32
3. 327 kg per la OMNIA42
The overall dimensions are:
OMNIA
A 1260mm
B 1000mm
C 1740mm
C
B
2. HOW TO UNPACK THE MACHINE
1. Take off the outer package
2. The machine is fixed on the pallet with metallic brackets
3. Take off these brackets and possible wedges which block the wheels
Note
Remember to reset the fastenings removed to take off the brackets
4. Using a chute, get the machine down from the pallet, pushing it in reverse motion. Avoid violent
blows to the base
5. Keep the pallet and the fixing brackets for eventual transport necessities
3. CABLE CONNECTION TRACTION MOTOR
A technician of the Comac service dept. must carry out this operation.
4. INSTALLATION OF THE BATTERIES INTO THE MACHINE
The batteries are fitted in the appropriate compartment under the solution tank and must be handled
by using appropriate lifting equipment suitable both for the weight and for the coupler system. They
must moreover satisfy the requirements quoted in the Specification CEI 21-5. Dimensions of the
battery compartment: 436 x 614 x H510 mm
ATTTENTION! For maintenance and daily recharge of the batteries, it is
necessary to follow strictly all the indications given from the constructor or
from his dealer.Specialized staff must carry out all the installation and
maintenance operations.
