Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 3
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #3.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Analog input: Cold temp 4
If there is an additional terminal board between a thermocouple and the IS-AIN8
module and there is a significant temperature difference between this terminal
board and the module, it is necessary to measure the temperature at this terminal
board and use this temperature for the thermocouple compensation instead of the
internal temperature of the module.
This analog input is intended for measuement of this thermocouple compensation
temperature for the IS-AIN8 module with index #4.
NOTE:
Thermocouples without internal compensation "Thermo(nc)..." must be used for
this case.
Table of binary output functions
Binary output: Starter
The output is used to energize the starter motor. The output closes at the begining
of start sequence after prestart has been completed and opens when the engine
is started.
NOTE:
Learn more in the separate chapter Starting sequence.
Binary output: Fuel Solenoid
This output is used for control of the engine fuel valve. The fuel valve can be
either a fuel solenoid of diesel engine or a gas valve of gas engine. The behavior
